CS 111 – Fall 2005
Synchronization Notes
Lecture 8 – October 25th,
2005
Original
content added to by: Shyam Toprani & Marc Heusser
Orginal Creation time:
CS 111 – Spring 2005
Synchronization & Deadlock Notes
Lecture 8 – April 27, 2005
Authors: Kimbo Djakaria, Cory Weng, Brian Leung, Leslie Choong
Locks
Where do we put locks in a program? And how many locks should there be? These questions have motivated the designs of several different locks and synchronization mechanisms.
The most basic choice is between having few coarse-grained locks and many
fine-grained locks. To summarize the advantages and disadvantages:
Few coarse-grained locks |
+
Correctness is easier (with only one lock, there's less chance of grabbing
the wrong lock, and less risk of deadlock) |
|
|
Many fine-grained locks |
+ Good
concurrency/parallelism = good performance |
Let's dig a little deeper. Say that we have two programs, P1
and P2, that are trying to write 1
and 2
characters into a
buffer. The buffer should be filled up with 1
s and 2
s from left
to right, but neither process should never overwrite a buffer slot already used
by the other. (See WeensyOS 2.)
We want the buffer to contain the right number of ones and twos, i.e.
1 |
1 |
2 |
2 |
|
|
|
|
||
|
P1 last wrote here |
|
P2 last wrote here |
|
We don't want a race condition to occur where one of these
processes overwrite the other one's data.
1 |
2 |
|
|
|
|
|
|
|
|
|
|
P1 last wrote here |
|
|
The simplest way to guarantee synchronization is to put each
of the processes entirely in its own critical section, so one process
runs into completion before the other one starts. This strategy is very
coarse-grained: we have just one lock, which essentially covers all system
resources. This solution is pretty easy to program! Each process can simply
acquire the single lock at the beginning, then release it at the end. (Or, even
easier, we could wait for the first process to exit()
before launching the second
process.) On the other hand, there's no concurrency in the system!
To achieve greater concurrency -- and often better performance -- we can move to finer-grained locks. Rather than protecting all system resources, each fine-grained lock will protect a single resource, or a small number of them. Rather than holding a lock for a long time (as above, where a process holds the whole-system lock for as long as it runs), each process will hold this lock for as little time as possible while still providing protection. In this example, we might have a lock that protects buffer accesses; each process grabs the lock, writes a single character into the buffer, releases the lock, and repeats.
The advantage of this approach is concurrency (and therefore performance). In a coarse-grained locking system, a process will often hold a lock that protects a resource it doesn't access. For example, the coarse-grained lock above, which covers all system resources, protects the network as well as the buffer; but neither P1 nor P2 accesses the network! A process P3 that wants to access the network has to wait for P1/P2 to release the lock first, even though it could safely run in parallel with either of them. This prevents meaningful concurrency. In a fine-grained locking system, processes aim to hold minimal sets of locks. In our example, P1/P2's lock covers just the buffer, not the network, so P3 could access the network in parallel with P1/P2 accessing the buffer. There are two disadvantages. First, overhead. There are many more locks in the system, and each lock takes some space; and there are many more lock acquire/release operations, each of which takes some time. And second, programmability. With many locks, each protecting a handful of resources, it's a lot harder to tell which locks are needed to safely execute some operation; it's easy to forget a lock or cause a deadlock.
The reason people have invented so many different synchronization objects is to try to find a sweet spot on the continuum where you have fine-grained locking so that performance is high but easy enough to program so mistakes can be avoided.
Different kinds of locks:
1. Mutex (Mutual Exclusion)
The mutex is the simplest kind of lock. It has two operations:
typedef struct mutex {
int l;
} mutex_t;
1. acquire(mutex_t *m) {
while (m->l == 1)
sleep & try again;
m->l = 1; /* atomic with the 'm->l == 1' check above */
}
2. release(mutex_t *m) {
m->l = 0;
}
How coarsely-grained or finely-grained is a mutex? Where does Mutex lie on the spectrum? One can have many mutexes on a program. Mutex is the mechanism used to implement all other functions of synchronization in a program. If you have one mutex protecting an entire program, then it is coarse-grained locking. If you have many mutex, say, one per integer in your program that you might want to read or write, then you have fine-grained locking.
Example
of fine-grained locking: (Let’s say code below is for a bank program).
getNewBalance
(myTotal, myInt){
int balance;
printf(“Start account math”);
acquire(m);
myTotal += myInt;
release(m);
printf(“Ending account math”);
acquire(m);
balance += myTotal;
release(m);
}
Example
of coarse-grained locking (compared to previous example):
acquire(m);
getNewBalance
(myTotal, myInt);
release(m);
As
seen from the first example, the programmer decides to push fine-grained
locking to the limit by using acquire() & release() for each time he/she
feels there is a potential synchronization issue. (Once for each line of code
where a calculation takes place.)
In the more coarse-grained approach the
programmer decided to call acquire() & release() only once for the entire
area in question.
Block Synchronization (Java synch)
People have used programming languages to attempt to hide these acquire and release operation. One of the current ones is called block synchronization and this is the kind of synchronization that Java has. Every object has a secret mutex.
Object o {
mutex lock; // this is hidden
int i;
void inc() {
synchronized (this) {
// everything in this section is atomic
// with respect to other "synchronized" blocks
// on this object
i++;
}
}
}
What does the synchronized section compile to in Java?
Object o {
mutex lock; // this is hidden
int i;
void inc() {
// synchronized (this) {
lock.acquire();
i++;
lock.release();
// }
}
}
Why wouldn't it be easier to just call acquire and release directly? Because you might forget to release. This kind of error actually happens all the time.
Let's change the definition of inc(). inc() is going to send an error if i is negative; we are only supposed to increment if i is positive.
Object o {
mutex lock; // this is hidden
int i;
int inc() {
lock.acquire();
if (i < 0)
return -1;
i++;
lock.release();
return 0;
}
}
Where is the error?
If
i
is negative, the function returns without releasing the lock. But if we
get replace the explicit acquire and release with a synchronized
statement, the compiler will be smart enough to see that when we return -1
inside the if
statement, the lock should be released. Thus, lock synchronization is a
way to avoid common error condition.
Are these synchronized locks fine-grained or coarse-grained?
In Java, every object have a lock, therefore it is fine-grained.
Are there any costs to that?
Yes. If every object has a lock, then every object has to initialize the lock, create the lock, and create space for the lock, which in the end will lead to overhead.
Recursive Mutex
What happens when we have this?
synchronized (this) {
synchronized (this) {
i++;
}
}
Deadlock
occurs because the inner synchronized
can never obtain the lock that the outer synchronized
has already
acquired. The solution to this problem is a recursive mutex, which
allows the same thread to lock multiple times.
Implementation:
typedef struct rmutex {
int l;
pid_t pid;
} rmutex_t;
pid_t getpid(); // system call returns current thread's ID
void acquire(rmutex_t *m) {
while (m->l > 0 && m->pid != getpid())
sleep and try again;
m->l++; // atomic with "m->l > 0" check above
m->pid = getpid();
}
void release(rmutex_t *m) {
m->l--;
}
Any
lock that has already been acquired has an l
value greater than 0. The acquire
function takes in a lock, and checks if it has already been acquired. If
it has, then it checks m->pid
,
the PID value currently associated with the rmutex. If the PID matches
the PID of the process trying to obtain the lock, the process is allowed to
acquire the lock again. Thus, a thread that owns the lock for an object
can enter another synchronized
block for the same object. Release simply decrements l
, and in a
recursive mutex, the number of acquires equals the number of releases.
Read/Write locks
One common use for locking is to ensure that some object doesn't change while we read it. For instance, say we wanted to count the number of lines in a file. We might lock that file as we counted to ensure that no one could change the file as we worked. If we used a conventional mutex, would there be a performance/concurrency problem? Absolutely: only one process could read the file at a time. This seems a little overprotective (coarse-grained), since the line-counting process isn't changing the file!
To
solve this problem, we can introduce a read/write lock. This kind of
lock has four operations, not two. The acquire_read
and release_read
operations acquire the lock for reading the object, while the acquire_write
and release_write
operations acquire it for writing. However, multiple processes can be
in a "read" critical section simultaneously. That is,
"read" critical sections are non-exclusive. But "write"
critical sections are exclusive both with each other, and with "read"
critical sections: if you're writing the object, no one else can be writing or
reading it.
We can implement a read/write lock by using a conventional mutex. (A recursive mutex would be possible too.)
typedef struct rwlock {
mutex_t m;
int rcount;
} rwlock_t;
acquire_read(rwlock_t *rw) {
acquire(&rw->m);
rw->rcount++;
release(&rw->m);
}
release_read(rwlock_t *rw) {
acquire(&rw->m);
rw->rcount--;
release(&rw->m);
}
acquire_write(rwlock_t *rw) {
while (1) {
acquire(&rw->m);
if (rw->rcount == 0)
// no one is reading, we're done
return;
// otherwise, try again
release(&rw->m);
}
}
release_write(rwlock_t *rw) {
release(&rw->m);
}
Acquiring and releasing a read lock is straightforward, and simply increments or decrements rcount. However, acquiring a write lock is only possible if rcount == 0, in other words, if no other thread has a read or write lock on the object.
Read/write locks are most useful in the following situations:
1) In applications where it is easy to identify which threads only read shared data and which threads only write shared data.
2) In applications that have more readers than writers. Although read/write locks may require more overhead to establish than mutex locks, this is compensated by the increased concurrency of allowing multiple simultaneous readers.
Condition Variables
Sometimes
a process wants to wait for a condition other than mutual exclusion. For
example, say that a process wants to lock variable i
once that
variable reaches a value >= 2. How can we possibly implement this with
mutual exclusion?? The obvious way is just to busy-wait on the condition:
int i;
mutex_t i_mutex;
cond_t i_geq_2_cond;
...
acquire(&i_mutex);
while (!(i >= 2)) { // give another process a chance to run,
// so it can maybe set i to 2 or more
release(&i_mutex);
acquire(&i_mutex);
}
// Now we hold i_mutex, and i >= 2.
...
But like all busy waiting this has high overhead.
The
condition variable synchronization object was designed for this
application. A condition variable is associated with some mutual-exclusion
lock; there can be many condition variables per lock. The variable represents
some state of the program -- for example, "i >= 2
". A process that
wants to wait for this condition does the following:
int i;
mutex_t i_mutex;
cond_t i_geq_2_cond;
...
acquire(&i_mutex);
while (!(i >= 2))
cond_wait(&i_geq_2_cond, &i_mutex);
// Now we hold i_mutex, and i >= 2.
...
Now,
the system will put us to sleep until some program changes the state so that i
is 2 or
more. But how does the OS detect this state change? It relies on the
application! Application programs must signal the condition variable
when they might have made the condition true. (The signal operation is also
sometimes called "raise".) For example, the operation to increment i
must be
written like this:
void inc_i() {
acquire(&i_mutex);
i++;
if (i >= 2)
cond_signal(&i_geq_2_cond);
release(&i_mutex);
}
(This signalling protocol is pretty precise; instead, the process might signal the condition variable on every increment. The point is that we must signal the condition variable whenever there's any chance that the condition has become true.)
Here's how these operations are implemented.
void cond_wait(cond_t *cond, mutex_t *m) {
release(m);
sleep until someone calls cond_signal(cond);
// NB: The sleep operation occurs atomically with
// the release(m) operation, so there is no race
// condition.
acquire(m);
}
void cond_signal(cond_t *cond) {
wake up any processes waiting on cond_wait(cond);
// Might also wake up >= 1 waiter.
}
Semaphores:
Definition: An integer variable that, apart from initialization, is accessed only through two standard operations: acquire( ) and release( ).
Background: acquire( ) and release( ) used to be called P and V, Dutch for proberen "to test" and verhogen "to increment".
Usage: A lock (L) is initialized to the number of resources (corresponding to that lock) that is available. Then, acquire( ) checks to see if L is greater than 0, if it is not, then no resouces of this type is available. If it is greater than 0, then a resource is available and we decrement count of L. On release(L), L is incremented (to show that another one of these resources are available. If L is initialized to 1, then the lock is a mutual exclusion lock (only one process may grab it at a time). When more than one process can hold the lock ( L > 1 ) at a time, then it is called a "weak mutual exclusion".
Code: acquire(L):
if (L > 0)
L--;
return;
else
sleep and try again
release(L):
L++;
if (L > 0)
wake up 1 or more waiting processes
Example Problem (from the textbook): The
Dining Philosophers Problem
Let's say there are 5 philosophers around a table. They each have a plate of pasta, and there are 5 forks on the table also.While they are thinking, they don't touch a fork and don't eat the pasta. However, when they decide to eat, a philosopher must pick up two forks, one on its left and one on its right. After finished eating, the philosopher returns the forks to their original position and resumes thinking. However, while the philosopher is eating, a philosopher to the left or right can't eat because the forks are a shared resource (and for some reason they need 2 forks!).
How can the philosophers coordinate so they can all think and eat without any conflicts?
Attempted Solution (using semaphores)
semaphore fork[5];
philosopher(int i){
while (TRUE) {
// Think
// Eat
P(fork[i]);
P(fork[(i+1) mod 5]);
eat();
V(fork[(i+1) mod 5]);
V(fork[i]);
}
}
fork[0] = fork[1] = fork[2] = fork[3] = fork[4] = 1;
fork(philosopher, 1, 0);
fork(philosopher, 1, 1);
fork(philosopher, 1, 2);
fork(philosopher, 1, 3);
fork(philosopher, 1, 4);
Can you spot the problem here? Well, if the philosophers all pick up their left fork at the same time, they will deadlock! They will each try and lock the fork using P and it will be unavailable to any other philosopher.
So how can we solve it?
One method: AND synchronization. If a philosopher can’t obtain both forks,
there is no point in letting him obtain even one semaphore, because that will
cause problems for other philosophers.
This form is Psimultaneuous(S1,
…, Sn)
philosopher(int i){
while (TRUE) {
// Think
// Eat
P.sim(fork[i], fork[(i+1) mod 5]); // locks both forks at once
Eat();
V.sim(fork[(i], fork[(i+1) mod 5]);
}
}
semaphore fork[5];
fork[0] = fork[1] = fork[2] = fork[3] = fork[4] = 1;
fork(philosopher, 1, 0);
fork(philosopher, 1, 1);
fork(philosopher, 1, 2);
fork(philosopher, 1, 3);
fork(philosopher, 1, 4);
Note: the implementation for P.sim and V.sim can be seen on page 339. The basic idea is that it allows for simultaneous locks before any other process can access the items you are trying to lock.
Monitors:
Definition: A user defined type in languages such as Java. Only one process may access a function inside of a monitor at one time. Therefore, mutual exclusion is provided without all the errors that may occur in other synchronization methods such as Semaphores. (Block synchronization is 1 lock per object which is fine-grained locking. Monitors have 1 lock per class which is coarse-grained locking.)
Code: Monitor {
entry inc(i) {
i++;
}
}
Monitor.inc(i) and Monitor.inc(j) can not be done at the same time.
Another solution to the Dining Philosophers problem is possible using monitors. This monitor function allows for 3 states: eating (which means the philosopher is using 2 forks), hungry (the philosopher is waiting for a fork or two), or thinking (not waiting for any forks). The pickUpForks(i) monitor only allows the philosopher i to eat if the adjacent forks aren’t in use. If hungry, a philosopher will wait for a signal and only be granted access to the forks once the adjacent philosophers are done eating (after the adjacent philosophers have run putDownForks(i))
#define N
enum status (eating, hungry, thinking);
monitor diningPhilosophers{
status state[N];
condition self[N];
int j;
test(int i) { // internal function to the monitor
if ((state[i-1 mod N] != eating) &&
(state[i] == hungry) &&
(state[(i+1) mod N] != eating)) {
State[i] = eating;
Self[i].signal;
}
};
public:
pickUpForks(int i) {
state[i] = hungry;
test(i);
if (state[i] != eating) self[i].wait;
};
putDownForks(int i) {
state[i] = thinking;
test((i-1) mod N);
test((i+1) mod N);
};
DiningPhilosophers() { // initialize the philosophers to think
for(int i = 0; i < N; i++) state[i] = thinking;
};
}
Barriers:
Definition: A thread synchronization mechanism that allows several threads to run for a period of time but then forces all threads to wait until all have reached a certain point.
Usage:
Say we want to do M1 X M2 + M3 X M4 + M5 X M6 where M is a matrix. We can
parse the work to three different processes where:
P1: M1 X M2
P2: M3 X M4
P3: M5 X M6
Then we can have P1 add up the results from the work done by each one of these threads. In this case, we can block at a barrier (b) until all three have done their work and then have P1 execute the addition.
Code:
barrier(b) {
wait until everyone is at barrier b
continue
}
This needs to be given to each one of the processes.
Example problem:
Let’s assume that it is your job to write a multithreaded program for an international bank’s database (meaning thousands of transactions take place every second). This program is going to be used to read in all the current transactions from the individual accounts and at the same it will be calculating charges and interest. At the end of the month the bank will of course want to send out the statement of all the transactions, charges, and interest to the customers. However, your boss is very particular and he wants to immediately know the monthly statements even before the month is over (This means that the program will predict the monthly results based on all currently completed transactions). One method of writing this program would be to have three threads for calculating (updating) transactions, charges, and interest and to have these threads always running unless they finished all calculations for the entire month.
Even though the calculations for one thread may be finished you couldn’t create a statement without all three fields updated together. So you obviously would want to make the threads wait until all three threads are finished. Then and only then would you want to post the monthly summery for your boss.
This scenario clearly calls for the use of barriers since you need to prevent the three threads from creating the monthly statement until all threads have reached the end of the month. Once the threads are done with their work then the program should precede.
Wait-Free/Lock-Free Synchronization:
Definition: This is one of the most advanced methods of synchronization. We use atomic instructions and/or clever data structure design to achieve safe synchronization without locking.
Example:
Consider a function to increment a variable i
. With locking, it would look
something like this:
void inc(int *i, mutex_t *m) {
acquire(m);
(*i)++;
release(m);
}
But many architectures, including the x86, provide an instruction that provides the following semantics.
void compare_and_swap(int *addr, int old, int new) {
// x86 instruction "cmpxchg" is very similar
// All this is implemented as one atomic section:
if (*a == old) {
*a = new;
return 1;
} else
return 0;
}
Using
compare_and_swap
,
we can implement inc
without a lock:
void inc(int *i) {
int old;
do {
old = *i;
} while (compare_and_swap(i, old, old + 1) == 0);
}
Since there's no lock here -- and, thus, no need to go to sleep and wait for the lock to be released -- this is called wait-free or lock-free increment.
Example 2: Wait Free Queue:
If we have a circular queue and two pointers, one pointing to the head of the queue and the other pointing to the tail of the queue, then we have a data structure that allows reading and writing to the queue at the same time -- as long as there's exactly one reader and one writer. For more, see the last example in this code.
Deadlock occurs when the system halts forever -- with no further progress possible -- because processes are waiting for locks that will never be released. This is a big problem when we are trying to synchronize processes. On one hand we want to lock down specific resources so that other processes cannot create some undefined behavior, but by locking down a resource we create the possibility that other processes will be stuck waiting for a lock that the owner of the lock may unintentionally never release.
Let's try this thought experiment:
We are using non-recursive locks…
If this were to occur, the system would be deadlocked because we would never switch out of the interrupt handler, and therefore spend eternity and more waiting for a lock that Process 1 will never have a chance to release.
Let's try another thought experiment:
Here we have a different kind of problem. Since processes can be preempted anywhere it is possible that we could switch out from P1 after acquiring lock a, then P2 acquires lock b. Then P1 is stuck waiting for P2 to release lock b while P2 is stuck waiting for P1 to release lock a. Both processes are stuck and will churn away forever, fruitlessly hoping that one day they will find the right lock to call their own.
There are 4 conditions necessary for deadlock to occur:
It is easiest to prevent Number 1 (recursive locking?) and Number 4 (careful programming).
A technique called Lock Ordering can be used to help prevent circular waits. By assigning a total order to all the locks in a system, then circular deadlocks can be prevented.
acquire(l) is allowed iff (l.order > any other acquired locks order);
Try this out for yourself and reorder the situation above so that circular deadlock cannot occur. (you can order it however you like a,b,…. or b,a,….)
Is it possible to have a built-in Operating System Deadlock Detector? If so, what would the detector do if it found a deadlock? Should it kill the process? Should it send a scathing email to the maintainer of that program/process reprimanding them for their shoddy work?
While it is possible to have a deadlock detector, it seems a little impractical. We would be adding an extra layer that checked for deadlocks every so often and this can lead to overhead. Secondly, what exactly would the detector do? If it did kill a process, undefined behavior may begin to occur and who knows what would happen next. Programmers need to be aware of the issues and dangers involving synchronization and deadlocks and program defensively and wisely in order to prevent them. However, deadlock detection can be a useful part of that defensive programming. A system that periodically checks for deadlock, and if it finds it takes some aggressive action (like rebooting), can help a system survive much longer without human intervention.
A
deadlock preventor can make more sense. For example, the Unix operating
system supports read/write locks that protect arbitrary regions of files (using
the fcntl
system call, with operation F_SETLK/F_SETLKW
). Deadlock is a definite
possibility! Unix prevents it by causing the acquire attempt that would cause
deadlock to fail, with error EDEADLK
.
